Blowtech

Specifications			Unit	Datasheet
Forming	Cavity Pitch		mm	100
	Mould	WIDTH THICKNESS	mm	110 max 150 max
	Clamping Stroke		mm	150 max
	Stretching Stroke		mm	400 max
	No. of Cavity		pcs	Two
Product	Product Height		mm	350 max
	Container Volume		ml	30 min 1000 max
	Neck Outer Diameter (Max)		mm	28 – 30*
	Product Outer Diameter (Max)		mm	80
	Theoretical Production		pcs/hr	2400 Bottle for 300 ml / 2200 Bottle for 500 ml / 2000 Bottle for 1000 ml
Power	Total Consumption Power		kw	18 kw
	Total Consumption with Utility		kw	55 HP Connected Load
	Heating Power		kw	14 kw
	Number of Lamp		pcs	8
	GEAR Motor Conveyor Motor + Blower		kw	3.75kw
Air	Operation Pressure		kg/cm	8
	Air Consumption for System		cfm	16
	Blowing Pressure		kg/cm	30
	Air Consumption on max volume		cfm	108 cfm for blowing 30 cfm for System
