| Specifications | Unit | Datasheet | ||
|---|---|---|---|---|
| Forming | Cavity Pitch | mm | 140 | |
| Mould | WIDTH THICKNESS | mm | 300 max 160 max | |
| Clamping Stroke | mm | 150 max | ||
| Stretching Stroke | mm | 400 max | ||
| No. of Cavity | pcs | Two | ||
| Product | Product Height | mm | 300 max | |
| Container Volume | ml | 100 min 2000 max | ||
| Neck Outer Diameter (Max) | mm | 24 – 96* | ||
| Product Outer Diameter (Max) | mm | 110 | ||
| Theoretical Production | pcs/hr | 1600 Jars for 300 ml / 1400 Jars for 500 ml / 1300 Jars for 1000 ml 1800 for 1000 ml Bottles | ||
| Power | Total Consumption Power | kw | 25 kw | |
| Total Consumption with Utility | kw | 60 kw Connected Load | ||
| Heating Power | kw | 23 kw | ||
| GEAR Motor Conveyor Motor + Blower | kw | 7 kw | ||
| Number of Lamp | pcs | 16 | ||
| Air | Operation Pressure | kg/cm | 8 | |
| Air Consumption for System | cfm | 30 | ||
| Blowing Pressure | kg/cm | 30 | ||
| Air Consumption on max volume | cfm | 108 cfm HP for blowing 40 Cfm LP System | ||
